DIN 86037 PN10, 16

Material
S235JRG2 formerly (RSt 37-2, Werkst.-Nr. 1.0038 to DIN 17100).

Note
Steel flanges will be supplied ready galvanized.
Other coatings on request.


DIN 86037 PN10

  • DN 20 - DN 150

    DIN 2642 PN 10

  • DN 175

    DIN 86037 PN 16

  • DN 200 - DN 250

    DIN 2642 PN 10

  • DN 300 - DN 1200

    DIN 86037 PN 10


DIN 86037 PN10

Size







Approx. Weight

DN

OD

D

d1

b

k

d2



inch

mm

mm

mm

mm

mm

mm

mm

kg per piece

¾

20

25

105

28

14

75

14

0.81

1

25

30

115

33

16

85

14

1.11

32

38

140

42

16

100

18

1.64

40

44.5

150

50

16

110

18

1.86

2

50

57

165

62

16

125

18

2.20

65

76

185

81

16

145

18

2.62

3

80

89

200

94

18

160

18

3.32

4

100

108

220

113

18

180

18

3.67

5

125

133

250

138

18

210

18

4.54

6

150

159

285

164

18

240

22

5.60

7

175

194

315

200

22

270

22

6.50

8

200

219

340

225

20

295

22

7.46

10

250

267

395

273

22

350

22

10.30

12

300

324

445

331

24

400

22

12.10

14

350

368

505

375

24

460

22

15.70

16

400

419

565

426

26

515

26

20.10

18

450

457

615

465

28

565

26

25.40

20

500

508

670

517

30

620

26

30.80

24

600

610

780

618

32

725

30

40.50

28

700

711

895

720

34

840

30

54.00

32

800

813

1015

822

38

950

33

76.00

36

900

914

1115

923

42

1050

33

92.00

40

1000

1016

1230

1025

46

1160

36

120.00

48

1200

1220

1455

1230

50

1380

39

170.00


DIN 86037 PN16

Size













Approx. Weight

DN

OD

D

d1

b

k

d2

Bolt



inch

mm

mm

mm

mm

mm

mm

mm

Holes

kg per piece

¾ - 6

20 - 150

25 - 159

see above

7

175

194

315

200

22

270

22

8

7.5

8

200

219

340

225

22

295

22

12

8.0

10

250

267

405

273

24

355

26

12

15.0

12

300

324

460

331

28

410

26

12

16.1

14

350

368

520

375

32

470

26

16

23.4

16

400

419

580

426

36

525

30

16

30.9
